Technical Spec'
What’s In The Box | |
In The Box - Accessories | AC power cord 2 PCS, Battery (AAA) 2 PCS, HDMI Cable 1 PCS, Operation Manual 1 PCS, Optical Cable 1 PCS, Quick Guide 1 PCS, Remote Controller 1 PCS, Wall Mount Guide 1 PCS, Wall Mount Kit 1 Set |
What’s In The Box | |
Remote Control Keys | Bass +/-, Dimmer +/-, Movie, Music, Mute, News, Next/Previous (Navigation / BT / USB), On/Standby (SB), Play / Pause / Pairing (BT / USB), Source, Surround On / Off, Volume +/- |
Control Keys (On Main Unit) | |
Controls On Sound Bar (Front Panel) | Input/Source, On/Standby, Volume +/- |
Sound Enhancement | |
Virtual Surround | Support |
Decoder | |
Dolby Digital | Yes |
PCM | Yes |
MultichPCM | Yes |
Decoder Others | FLAC, MP3, WAV(48K), WMA |
Key Components | |
DSP | Sunplus 8109H-A |
HDMI IC/Module | Sunplus 8109S-A |
Functions | |
HDMI ARC | 1 |
BT Version | 4.2 |
Optical Input | 1 |
Coaxial Input | 1 |
Aux Input | 3.5mm Phone Jack |
Auto Power On | Yes (not for USB/Bluetooth) |
Auto Power Off | Yes (All) |
Wall Mountable | Yes |
USB port for Service (FW update) | Share USB Type A |
Bass Level Adjustment | Yes |
Amplifier | |
Amp Type | 2.1CH |
Rated Output (Sound Bar) | 27W x 2 + 54W (@10%THD) |
Rated Output Power (Total) | 108W |
Sound Bar (Frequency Response) | 40Hz-20KHz |
Speaker System | Full Range x 2 + Woofer x 1, Total 3 Speakers |
Woofer: Speaker Size | 3" |
C. Max SPL | 97.9 dB SPL |
Power Supply | |
Voltage | AC ~ 100-240V |
Frequency | 50-60Hz |
Phase | AC Input |
Power Consumption (Sound Bar) | 20W |
Power Consumption (Stand-by) | <0.5W |
Speaker | |
Full Range Speaker/ch (Size) | 44 x 100mm |
User Interface | |
LED indicator | Standby LED, Yes |
Specifications | |
Gross Weight (Kg) | 2.7 kg |
Net Weight (Kg) | 2.17 kg |
Net Dimension (W x H x D) | 650 x 95 x 58 |
More | |
Bluetooth Audio | Yes |
USB Audio (Type A) | Support, 1 port |
Weight | 2.17 kg |
---|---|
Dimensions | 65 × 15 × 10 cm |
Storage | 512GB SSD, 1TB SSD, 2TB SSD, 4TB SSD |
