Technical Spec'
Image display | |
Panel manufacturer | Hisense |
Panel model | LCM:HD750Y3U73-T0L4 Open Cell :HV750QUB-F91 |
Active display area, horizontal dimension (mm) | 1649.664 |
Active display area, vertical dimension (mm) | 927.936 |
Screen size (cm) | 189 |
Screen size (inch) | 75 |
Display technology | LCD/ LED lit |
Backlight source | Direct LED |
Resolution (Horiz x Vert) (pixel) | 3840X2160 |
Screen curvature radius (mm) | - |
Colour depth (bit) | 8bit+FRC |
Image refresh frequency (Hz) | 60 |
Smooth motion rate | 120 |
3D image | - |
Typical brightness of white (cd/m2) | 350 |
Native contrast ratio | 1200 : 1 |
Viewing Angle (Horiz / Vert) (Degrees) | 178/ 178 |
Quantum dot | NO |
Wide colour gamut | Yes |
KSF phosphor | Yes |
UHD Premium | No |
Response Time (ms) | 8 |
Connectivity | |
RF- Radio frequency input | 1 |
AV input | 1 |
AV output | 0 |
USB interface type 3.0 (Qty / List….) | 1/ USB 1 |
USB interface type 2.0 (Qty / List ….) | 1/ USB 2 |
Optical digital audio output (SPDIF) | 1 |
Earphone jack | 1 |
HDMI ports | |
HDMI inputs | 3 |
HDMI type 8K@60Hz | No |
HDMI type 4K@60Hz with HDCP version 2.2 | Yes |
HDMI 2.1 compliant input | Partial compliance. Supported HDMI 2.1 features: VRR, ALLM, eARC and QMS |
Enhanced Audio Return Channel ( eARC) | HDMI 2 |
CEC- Consumer Electronics Control via HDMI | HDMI 1,HDMI 2,HDMI 3 |
Smart TV | |
Ethernet port (RJ45 connector) | 1 |
Wi-Fi protocols IEEE 802.11 {b, g, n, ac, ad, ..} | a, b, g, n, ac |
Wi-Fi bands (GHz) | 2.4 / 5 |
Wi-Fi 6 | No |
DLNA compliance | Yes |
Bluetooth / BT version | Yes / 5.0 |
Anyview (Screen mirroring) | Yes |
UHD (4k) streaming | No |
Installed Applications {List ……} | Netflix/ Youtube/ Prime Video/ Foxtel/ Stan/ ABC iview/ Kayo/ Tubi/ SBS ON DEMAND/ Facebook Watch/ NBA |
Installed Applications {List ……} | Redbull TV/ Kidoodle TV/ FITE/ Plex/ Youtube Kids/ Game Center/ Toon Goggles/ Yupptv |
Freeview Plus - HbbTV 2.0 | Yes |
Web browser [Chrome | Opera | Other] | Odin |
Digital TV reception | |
Television system (DVB-T / DVB-T2) | Yes / Yes |
Video decoder (MPEG2 / MPEG 4) | Yes / Yes |
AC3 Surround sound decoder | Yes |
AS 4599.1 compliance | Yes |
AS 4933.1 compliance | Yes |
LCN- Logical channel number and DTV Service name support | Yes |
Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX | Yes / Yes / 4:3 |
Subtitles | Yes |
RF Signal strength indicator | Yes |
RF Signal quality indicator | Yes |
RF Bit error rate indicator | Yes |
EPG- Electronic programming guide, 7 days for all services | Yes |
Audio description (vision impairment aid) | Yes |
Parental rating lock | Yes |
Analogue TV reception | |
Colour-Sound systems in VHF band | PAL B |
Colour-Sound systems in UHF band | PAL B |
Stereo sound decoder {A2, Nicam, ….} | A2, NICAM |
Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX | NO/NO/NO |
Subtitles | NO |
Image processing | |
Backlight control | No |
Light sensing | No |
Dynamic backlight control | No |
Frame rate control | Yes |
Variable Refresh Rate (VRR) | Yes |
FreeSync | No |
Auto Low Latency Mode for VRR | Yes |
Local dimming/ controllable zones | No |
Zoom function settings | Automatic/16:9/4:3/Panoramic/Movie Zoom/Direct |
HDR - High Dynamic Range for luminance (DMP / Netflix / HDMI) | Yes / Yes / Yes |
HDR system (HDR10 / HDR10+ / Dolby Vision) | Yes /Yes |
HLG (Hybrid Log-Gamma) for HDR | Yes |
HEVC (H.265) decoder | Yes |
Dual image (PIP / POP) | No / No |
Motion enhancement and compensation (MEMC) | YES |
Input lag | 6 ms @4K @ refresh rate / VRR |
Sound | |
Audio power output per channel (Watt) | 15 |
Number of speakers (Tweeter / Midrange / Woofer) | 2 / 0 / 0 |
Automatic volume level (AVL) | Yes |
Audio equalizer | Yes |
Dolby Digital | Yes |
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….} | Dolby Atmos |
Lip-sync adjustment | Yes |
Features | |
On/off timer | Yes |
Power off if no signal | Yes |
Sleep timer | Yes |
Program lock | Yes |
OSD transparency control | No |
User interface | VIDAA U5 |
Software version OSD indication | Yes |
Legal requirements: Disclaimer / Acceptance of Terms | Yes / Yes |
Favourite channels list | Yes |
Electronic point of sales (E-POS) | Yes |
OTA- Over the air software updates | Yes |
Voice command | Near Field:Alexa & Google Assistant |
Screen mirroring {Miracast, Anyview Cast, ...} | Anyview Cast |
Smartphone remote control application {Rremote Now, ...} | Yes |
Replaceable demo video for Store mode | Yes |
Remote control via serial port | No |
USB media player | |
Personal Video Recorder | Yes |
Time Shift | Yes |
DTV Recording (EPG scheduling / start from Standby ) | Yes / Yes |
DivX decoder | No |
MPEG4 (H.264) / H.265 decoder | Yes / Yes |
DMP- Digital media player content (Music / Video / Photos / Text) | Yes / Yes / Yes / No |
DMP Auto-play | NO |
DMP for UHD content via USB | Yes |
DMP File allocation table (FAT / FAT32 / exFAT / NTFS) | Yes / Yes / No / Yes |
PVR File allocation table (FAT / FAT32 / exFAT / NTFS) | Yes / Yes / No / Yes |
Hotel lock | |
Protected Hotel lock submenu (Password / fixed code) | No / No |
Clone function for programs, sound and image settings. | YES |
Sub-menu lock, including tuning lock | YES |
Keyboard lock | YES |
Maximum volume lock | YES |
Power on volume | YES |
Power on, apply default sound/image settings | NO |
Power on source selection | YES |
Power on RF channel selection | YES |
Power on mode (On / Standby / Last) | YES / YES / YES |
Inputs access (Enable / Disable) | No |
Hardware | |
Processor / Cores | NT72671 / 4 |
Dual Tuner | No |
Colour (Front bezel, rear, stand) | Tarnish / Black / Tarnish |
Speakers mounted in enclosure | Yes |
Mains power switch | No |
Swivel base | No |
Compact packaging | Yes |
Supply range [Voltage / Frequency] (Volt / Hz) | 100 ~ 240V / 50, 60Hz |
Standby consumption (Watt) | < 0.5W |
Maximum time delay Power On to sound an image (sec) | |
Installation | |
Stand area (Width / Depth) (mm) | 1130×366 |
Wall mount dimensions (Horiz x Vert) (mm) | 400/300 |
Wall mount, screw thread (mm) | M6 |
VESA compliance | Yes |
Detachable power cord | Yes |
Power cord length (cm) | 155 |
Accessories | |
Remote controller (Technology / Part number ) | BT / ERF3G80H/ ERF2E36H |
Battery (size / quantity) | AAA / 2 |
User manual (Available online) / Quick setup guide (Print) | 1 / 1 |
Warranty [In User manual | In separate sheet] | In separate sheet |
3D glasses type [Passive | Shutter] / Link [RF | IR | BT] | - |
3D glasses (Qty / Part number) | - |
Dimensions | |
Dimensions with stand (W/H/D) (mm) | 1675×1042×366 |
Dimensions without stand (W/H/D) (mm) | 1675×960×78 |
Carton box dimensions (W/H/D) (mm) | 1865×179×1146 |
Net weight (with stand / without stand) (kg) | 28.5 kg /28 kg |
Gross weight (kg) | 39 kg |
Container load (20ft / 40ft / 40ft HC) | 80/164/164 |
Licensing and certification | |
EMC- Electromagnetic Compatibility | Yes |
CB- Electrical safety | Yes |
HDMI | Yes(Hisense internal test) |
Dolby Digital | Yes |
MEPS- Test report | Yes |
ROHS | No |
Electrical safety conformity for Australia | Yes |
Documentation | |
Panel specifications | Yes |
Initial specifications (input form) | Yes |
Confirmed product specifications | Yes |
List of DMP formats for audio and video | Yes (QSG) |
Documentation | |
CB report and certificate | Yes |
EMC report and certificate | Yes |
Power cord, plug and connector Australian safety approval | Yes |
Weight | 39 kg |
---|---|
Dimensions | 167.5 × 104.2 × 36.6 cm |
